Brushless Motor RPM Sensor - universal - BeastX
Universal phase speed sensor for brushless motors.
In combination with common flybarless and telemetry systems, this sensor can achieve perfect speed control, even if only a cost-effective motor controller is used.
In contrast to most competing products, this sensor has a high measurement resolution even at low engine speeds.
Characteristics:
- Universal RPM sensor for the most common FBL and telemetry systems.
- Ideal for using the speed controller function in the MICROBEAST PLUS and MICROBEAST PLUS HD.
- The optional adapter cable BXA76401 is required to connect to the MICROBEAST PLUS and MICROBEAST PLUS HD.
- High measurement resolution, even at low speeds.
Technical data:
Operating voltage: 3.5V - 15.0V DC
Current consumption: max. 1.5mA
Sensor input voltage: Phase1, Phase2: 6V - 60V / Cells: 2S - 14S
Max. engine speed: 240,000rpm
Dimensions: 22x8x6.5mm
Weight: 2g
